ER308LSI Stanless Steel Gas-Shielded Solid welding wires

Standard：AWS A5.9
Material：ER308LSI
Surface：BRIGHT
Techinque：COLD DRAWN

ER308LSI Gas-Shielded Solid welding wires:The main component is low C-18Cr-8Ni, and Si element is added,the molten iron has good fluidity, and the welding seam is beautiful. It is suitable for high……

Send email to us

ER308LSI Gas-Shielded Solid welding wires:
The main component is low C-18Cr-8Ni, and Si element is added,
the molten iron has good fluidity, and the welding seam is beautiful. It is suitable for high-speed welding.

Chemical Composition of ER308LSI stainless steel welding wire:

Grade	Welding wire chemical composition（Wt%）
Grade	C	Mn	Si	Cr	Ni	Mo	P	S	Cu	Other
ER308LSI	0.015	1.75	0.9	20.02	9.85	0.03	0.015	0.01	0.15

Product Welding Reference Current(AC Or DC+):

Wire diameter(mm)		￠0.8	￠1.0	￠1.2
Welding current(A)	Flat welding, horizontal welding	70-150	100-200	140-220
	vertical welding	50-120	80-150	120-180
	Overhead welding	50-120	80-150	160-200

Specification :

Wire diameter	￠0.8mm	￠1.0mm	￠1.2mm
Package weight	12.5Kg/Spool	15Kg/Spool	15Kg/Spool

Some other Grade From Allin Metal Production:

AWS	Chemical composition of stainless steel welding wire(%)
AWS	C	Si	Mn	P	S	Cr	Ni	Mo
ER307Si	0.075	0.78	6.7	0.022	0.01	19.8	8.8
ER308	0.045	0.45	1.9	0.02	0.009	20.8	9.8
ER308Si	0.045	0.85	1.5	0.022	0.01	20.8	9.8
ER309	0.06	0.45	1.9	0.019	0.009	24.3	13.2
ER309Si	0.06	0.79	1.95	0.019	0.009	24.7	13.2
ER309L	0.02	0.42	1.8	0.02	0.01	24.8	13.2
ER309LSi	0.018	0.8	1.7	0.02	0.01	23.5	13.5
ER330	0.2	0.38	1.5	0.022	0.01	16.5	34.5
ER316	0.04	0.4	1.9	0.02	0.01	19.5	11.8	2.3
ER316Si	0.05	0.7	1.92	0.02	0.01	19.5	11.8	2.3
ER316L	0.019	0.38	1.8	0.018	0.01	19.8	12.2	2.5
ER316LSi	0.06	0.85	1.7	0.022	0.01	18.8	12.6	2.4
ER317L	0.02	0.38	1.8	0.02	0.01	18.8	13.8	3.6
ER318	0.06	0.42	1.5	0.022	0.01	18.5	11.8	2.3
ER320	0.06	0.4	1	0.022	0.01	19.8	33.3	2.8	Nb0.7
ER320L	0.018	0.33	1.5	0.013	0.01	19.8	33.6	2.5	Nb0.35
ER321	0.06	0.45	1.5	0.022	0.01	20.8	9.8		Ti9×C-1.0
ER347	0.055	0.48	1.8	0.021	0.008	20.8	9.8		Nb1×C-1.0
ER310	0.09	0.5	1.66	0.02	0.01	25.5	20.5
ER385	0.02	0.3	1.5	0.018	0.01	20.2	24.8	4.8	Cu 1.80
ER2209	0.022	0.5	0.9	0.02	0.01	22.5	8.8	3.3	N0.08-0.20
ER2553	0.027	0.5	1	0.025	0.015	24.8	5.5	3.2	N0.1-0.25
ER312	0.09	0.38	1.5	0.022	0.01	29.5	8.5
ER309LMo	0.023	0.45	1.5	0.022	0.01	23.8	13.2	2.2
ER630	0.04	0.39	0.5	0.022	0.01	16.5	4.8		Cu;3;Nb;0.28
ER453s	0.06	0.3	0.4	0.022	0.01	25.8	4.8	2.1
ER209	0.04	0.4	4.5	0.022	0.01	21.5	10.8	2.2	N;0.20;V;0.18
