SS 316 / 316L Chemical Composition :
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 |
| SS 316L | 0.03 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 10.00 – 14.00 |
Stainless Steel 316 / 316L sheet Equivalent Grades:
| TYPE | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| 316 | 1.4401 / 1.4436 | S31600 | SUS316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
| 316L | 1.4404 / 1.4435 | S31603 | SUS316L | 316S11 / 316S13 | 03Ch17N14M3 / 03Ch17N14M2 | Z3CND17‐11‐02 / Z3CND18‐14‐03 | X2CrNiMo17-12-2 / X2CrNiMo18-14-3 |
ASTM A480hot rolled sheet/coil thickness tolerance.
| thcikness，in.[mm] | Deviation, allowed for the specified width （w）,±，in.[mm] | |
| w≤60[1525] | w＞60[1525] | |
| 0.072[1.83] | 0.006[0.15] | 0.009[0.22] |
| ＞0.072[1.83]-0.083[2.11] | 0.007[0.18] | 0.010[0.25] |
| ＞0.083[2.11]-0.098[2.49] | 0.008[0.20] | 0.011[0.27] |
| ＞0.098[2.49]-0.114[2.90] | 0.009[0.23] | 0.012[0.30] |
| ＞0.114[2.90]-0.130[3.30] | 0.011[0.27] | 0.013[0.33] |
| ＞0.130[3.30]-0.145[3.68] | 0.012[0.30] | 0.013[0.33] |
| ＞0.145[3.68]-0.1875[4.76] | 0.013[0.33] | 0.014[0.35] |
| ＞0.1875[4.76]-0.250[6.35] | -0.010[0.25],+0.020[0.50] | -0.010[0.25],+0.020[0.50] |
| ＞0.250[6.35]-0.3125[7.94] | -0.010[0.25],+0.022[0.55] | -0.010[0.25],+0.022[0.55] |
| ＞0.3125[7.94] | -0.010[0.25],+0.030[0.75] | -0.010[0.25],+0.030[0.75] |
ASTM A480cold rolled sheet/plate thickness tolerance
| thcikness ，in.[mm] | Deviation, allowed for the specified width （w）,±，in.[mm] | ||
| W≤40[1000] | 40[1000]＜w≤50[1300] | 50[1300]＜w≤84[2100] | |
| 0.012[0.30] | 0.001[0.030] | – | – |
| 0.016[0.40] | 0.0015[0.04] | 0.0015[0.04] | – |
| 0.020[0.50] | 0.0015[0.04] | 0.0015[0.04] | – |
| 0.024[0.60] | 0.002[0.05] | 0.002[0.05] | – |
| 0.032[0.80] | 0.002[0.05] | 0.002[0.05] | – |
| 0.040[1.00] | 0.0025[0.06] | 0.0025[0.06] | 0.003[0.08] |
| 0.047[1.20] | 0.003[0.08] | 0.003[0.08] | 0.003[0.08] |
| 0.059[1.50] | 0.003[0.08] | 0.003[0.08] | 0.004[0.10] |
| 0.079[2.00] | 0.004[0.10] | 0.004[0.10] | 0.0045[0.11] |
| 0.098[2.50] | 0.004[0.10] | 0.004[0.10] | 0.005[0.13] |
| 0.118[3.00] | 0.005[0.13] | 0.005[0.13] | 0.006[0.15] |
| 0.157[4.00] | 0.007[0.17] | 0.007[0.17] | 0.007[0.17] |
| 0.197[5.00] | 0.007[0.17] | 0.007[0.17] | 0.0075[0.19] |
| 0.236[6.00] | 0.007[0.17] | 0.008[0.20] | 0.009[0.23] |
| 0.3125[8.00] | 0.007[0.17] | 0.009[0.23] | 0.010[0.25] |
